Lithium Battery Materials Conductive Carbon Coated Copper Foil
Conductive carbon coated copper foil can replace conventional Al foil as better anode substrate with improved properties.
----Better electrical conductivity and less internal resistivity
----Better mechanical strength and toughness to avoid short circuit caused by dendrite growth
----Better coating strength with electrode material
----Therefore, it will provide larger discharging capability and longer service life for Li-Ion batteries
Technical specification of coated carbon copper foil
No. | Item | Standard | Testing | |
1 | Cu purity | % | ≥99.8 | ≥99.95 |
2 | Penetration hole | piece | No | No |
3 | Single-sided carbon coating quality | g/㎡ | Copper areal density +0.65 | Copper areal density +0.65 |
4 | Double-sided carbon coating quality | g/㎡ | Copper areal density +1.3 | Copper areal density +1.3 |
5 | Mass resistivity | Ω.g/㎡ | ≤0.17 | 0.168 |
6 | Thickness tolerance | um | 1 | 1 |
7 | Tensile strength | kg/㎡ | ≥30 | 35 |
8 | Room temperature elongation | % | ≥3.5 | 4.2 |
9 | High temperature elongation | % | ≥4.0 | 5.5 |
We could supply one stop solution ( turn key project) for you.
1.Full set of lithium battery materials,including :
LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other
cathode&anode battery materials;Aluminum foil,copper
foils,battery separator,etc.
2.Full set of lithium battery equipments,for example:
mixing machine --coating machine--oven--rolling machine--welding
machine--slitting / cutiing machine --winding machine--sealed
machine,etc.
3.Full set of lithium battery technology.
we can design the laboratory and production line,according to
customer's request.
![]() |
