    Microporous Aluminum Foil Lithium Battery Materials Electrode Sheet

    Ask Lasest Price
    Brand Name : Gelon
    Model Number : GN-AF
    Certification : CE
    Price : $40-$60/roll
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10000 rolls per month
    Delivery Time : 7 working days
    • Product Details
    • Company Profile

    Microporous Aluminum Foil Lithium Battery Materials Electrode Sheet

    Microporous Aluminum Foil Lithium Battery Materials Electrode Sheet


    This aluminum foil (16 um) is used as substrate (Al current collectors) for coating cathode materials in Li-Ion rechargeable battery research. (Sold per roll only).


    Specifications

    1. Material: Aluminum , Purity > 99.3% 2.Resistivity:
    2. 7 x 10-8 Ohm-metre
    3. Length: 350 m
    4. Width: 280 mm
    5. Thickness: 16um 6.Density: 3.741 g·cm−3
    7. Tensile Strength: ≥150N/m3
    8. Alloy no. A1235
    Aluminum foil specification
    Application
    Lithium ion battery
    Polymer battery
    Aluminium strip
    Alloy
    1145 1235 1235A 8021 8150 1070
    1235A 8021 8150
    1145 1060 1100 1070 1200
    Temper
    H18
    0 H22 H18
    0 H18
    Thickness( mm)
    0.01-0.02
    0.012-0.06
    0.08-0.15
    Mechanical
    Performance
    U.T.S (Mpa)
    ≥40Mpa
    ≥40-150
    ≥75
    Elongation(%)
    ≥1
    ≥1
    ≥20
    Core (ID) mm
    76.2
    76.2
    76.2
    Wettability
    ≥B grade
    ≥B grade
    ≥B grade

    We could supply one stop solution ( turn key project) for you.

    1.Full set of lithium battery materials,including :
    LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials;Aluminum foil,copper foils,battery separator,etc.

    2.Full set of lithium battery equipments,for example:
    mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.

    3.Full set of lithium battery technology.
    we can design the laboratory and production line,according to customer's request.
