    Roll To Roll Battery Manufacturing Machine Electrode Calendering Machine

    Ask Lasest Price
    Brand Name : Gelon
    Model Number : GN-HR330
    Certification : CE
    Price : USD38850/set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 5set/month
    Delivery Time : 35 working days
    • Product Details
    • Company Profile

    Roll To Roll Battery Manufacturing Machine Electrode Calendering Machine

    Roll To Roll Electrode Calendaring Machine With Heating Function Battery Manufacturing Machine


    The calendaring machine is the main equipment in the continuous calendaring production line. It consists of cast steel gantry frame, rolls, frequency conversion motor reducer, gap adjustment system, electrical control system, feeding guard plate and roll surface cleaning mechanism.
    The main function is to make the electrode reach the appropriate density under the rolling of the roller, and meet the electrode thickness requirement according to the coating thickness.


    GN-HR-330 hydraulic roller pressure machine is an automatic battery electrode rolling press system with precision digital pressure control . The pressure can be adjusted easily by touch screen.


    Name
    Pressure Adjust Hydraulic Rolling Press Machine
    Function
    Calender battery electrode
    Calender Model
    Hydraulic press
    Roller Size
    210mmDia*300mmW, 9Cr3Mo materials
    Calender Thickness
    0.01-2mm adjusted
    Effective Working Width
    Max 300mm
    Speed
    2-8r/min
    Efficiency
    0-5M/min
    Accuracy
    0.003mm
    Main Motor Power
    18KW(380V 50Hz)
    Heating
    6KW*2
    Max Working Pressure
    80T
    Rolling Press Machine Size
    About L2200mm*W1300mm*H1400mm
    Weight
    About 2000kg
    Warranty
    One-year limited warranty with all lifetime support

    Quality Roll To Roll Battery Manufacturing Machine Electrode Calendering Machine for sale
