Lithium Ion Battery Electrode Making And Winding All-in-one Machine Battery Equipment Battery Assembly Line

Description:
This machine is mainly used for precision winding of 18650 batteries. The working process is as follows: the positive and negative plates are manually introduced into the winding part, stacked with the separator, and wound according to the process requirements, the termination tape is automatically attached, and the battery core is automatically discharged.

Technical Parameter:

Rolling needle combination width: 6～15mm;
Diaphragm width: 10～40 mm;
Electrode width: 8～38 mm;
Electrode length: 60～300 mm;
Termination tape width: 8～15 mm;
Winding accuracy: diaphragm and anode electrode, the alignment error of the anode electrode and the cathode electrode sheet is less than ±0.5 mm;
Requirements for materials:
a. The width error of the pole piece is less than 0.1mm;
b. The "S" bending error of the pole piece is less than 0.5mm/1000mm, and there must be no edge warping;
c. The tower shape error of the diaphragm roll is less than ±0.2mm, and there must be no edge warping;
Equipment capacity: 6 to 10 PPM (related to the length of the pole piece and the manual feeding speed);
Drum shell rate:
Cell thickness ≤ 6mm, drum shell rate < 2%;
Cell thickness>6mm, drum shell rate<3%;

Index:

What we supply:
1. Full set of lithium battery materials, including :
LiFePO4, LiMn2O4, LTO, LiNiMnCoO2(NMC), LiCoO2, Graphite(MCMB)and Other Cathode&Anode Battery Materials; Aluminum foil, Copper foils, Battery separator,etc.

2. Full set of lithium battery equipment, for example:
mixing machine --coating machine--vacuum oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.

3. Full set of lithium battery technology.
We can design the laboratory and production line according to customer's request.
Any more info, pls kindly contact : mavis@libgroup.net

Gelon Teams since 2003 engaged in battery business,Enterprises from the initial Ni-MH battery production extends to the production of lithium ion battery materials and battery . Most of the senior management staffs graduated from China's most famous electrochemical professional --CENTRAL SOUTH UNIVERSITY, from which created a lot of leaders in Chinese lithium ion battery industry such as Mr ChuanFu Wang(BYD),Mr XinDe Xia, Mr KaiHua Xu, Professor GuoRong Hu and XinHai Li Etc. Owning a group of experienced engineers and staffs, we can bring you not only reliable products and technology, but also excellent services and real value you will expect and enjoy. Gelon Focus on manufacturing and selling of new materials (anode, cathode, separator, additive etc. ) for lithium ion battery, and also offer full sets of materials solution to customers. Our preponderant products are Lithium Iron Phosphate(LFP), Lithium Manganese Dioxide(LMO), Lithium Cobalt Oxide(LCO), Lithium Nickel Manganese Cobalt Oxide(NMC), Lithium Nickel Aluminum Oxide(NCA) ,Lithium Titanate Oxide(LTO) materials; Graphite materials (MCMB) , Separator & Other accessories (SBR CMC NMP PVDF,Sup-Li,Al&Ni Tabs )etc for new power lithium ion batteries. Meanwhile, we have our own lithium ion battery factory who mainly produces lithium ion battery for camera, mobile, EV application. Based on our battery production line, we can offer all services (Raw Materials, Equipments, Production line design &Technology, etc. ) for full set of equipments to help clients to set up Lab & Pilot line for lithium ion battery. Bynow, Gelon have finished many turn key project in Bolivia,Indonesia, Indian, Russia,Turkey and South Africa We have a more than ten years professional and experienced exporting teams to supply perfect services for all our customers. We are confident on our quality and service.And ensure to offer the best services based on our specialty and empressement. Our Aim is to be the comprehensive company dealing with One-Stop services for Lithium ion battery in the world. Our Business Philosophy: You choose us, We promise you What we offer to you,are what we are using Integrating the quality resources in China, delivering the best service and products to you. The best product we can provide, is our sincerity and reliability.
